EOS Aluminium Constellium CP1
Material Data Sheet | Powder Product No. 9030-0034
EOS Aluminium Constellium CP1
Aluminum-Iron-Zirconium alloy with high strength and good thermal stability
- High strength with good ductility
- Good electrical and thermal conductivity
- Excellent corrosion resistance
- Easily anodized due to its silicon-free composition
- Simplified heat treatment with no quenching required
- Heat exchangers
- Components requiring high-quality surface finishing, polishing, and anodization
- Parts exposed to corrosive environments
- Semiconductor industry applications
- Lightweight structural components with moderate mechanical load requirements
The EOS Quality Triangle
Material Data Sheet | Powder Product No. 9030-0034
EOS uses an approach that is unique in the AM industry, taking each of the three central technical elements of the production process into account: the system, the material and the process. The data resulting from each combination is assigned a Technology Readiness Level (TRL) which makes the expected performance and production capability of the solution transparent.
EOS incorporates these TRLs into the following two categories:
All of the data stated in this material data sheet is produced according to EOS Quality Management System and international standards
EOS incorporates these TRLs into the following two categories:
- Premium products (TRL 7-9): offer highly validated data, proven capability and reproducible part properties.
- Core products (TRL 3 and 5): enable early customer access to newest technology still under development and are therefore less mature with less data.
All of the data stated in this material data sheet is produced according to EOS Quality Management System and international standards
POWDER PROPERTIES
The chemical composition of the EOS Aluminium Constellium CP1 powder is according to composition of SAE AMS 7074 and AA8A61.50.
Powder Chemical Composition (wt.-%)
| Element | Min. | Max. |
|---|---|---|
| Al | Balance | |
| Fe | 0.8 | 1.2 |
| Zr | 0.9 | 1.35 |
| Si | - | 0.3 |
Powder Particle Size
| Generic Particle Size Distribution | 20 - 63 µm | |
HEAT TREATMENT
4 hours at 400 °C
No careful control needed for heating or cooling.
Process Data Sheet
EOS Aluminium Constellium CP1 for EOS M 290 | 60 µm
EOS M 290 - 60 µm - TRL 3
| System Setup | EOS M 290 |
|---|---|
| EOS Material set | AlCP1_060_M291 |
| Powder Product No. | 9030-0034 |
| Software Requirements |
EOSPRINT 2.13 or newer |
| Recoater Blade | HSS (High Speed Steel) |
| Build Platform Temperature | 125 °C |
| Nozzle | EOS Grid Nozzle |
| Inert gas | Argon |
| Sieve | 90 µm |
| Additional Information | |
|---|---|
| Layer Thickness | 60 µm |
| Volume Rate | 10.1 mm³/s |
Chemical and Physical Properties of Parts
Microstructure of the Produced Parts
| Defects | Thickness | Result | Number of Samples |
|---|---|---|---|
| Average Defect Percentage | 60 µm | 0.4 % | - |
| Density EN ISO 3369 | Thickness | Result | Number of Samples |
|---|---|---|---|
| Average Density | 60 µm | ≥ 2.73 g/cm³ | - |
Mechanical Properties
Mechanical Properties Heat Treated
| EN ISO 6892-1 Room Temperature | 60 µm | Yield Strength [MPa] | Tensile Strength [MPa] | Elongation at Break A [%] | Reduction of Area Z [%] | Modulus of elasticity [GPa] | Number of Samples |
|---|---|---|---|---|---|---|
| Vertical | 300 | 340 | 10 | - | - | - |
| Horizontal | 300 | 340 | 12 | - | - | - |
4 hours at 400 °C
No careful control needed for heating or cooling.
Mechanical Properties As Manufactured
| EN ISO 6892-1 Room Temperature | 60 µm | Yield Strength [MPa] | Tensile Strength [MPa] | Elongation at Break A [%] | Reduction of Area Z [%] | Modulus of elasticity [GPa] | Number of Samples |
|---|---|---|---|---|---|---|
| Vertical | 140 | 200 | 18 | - | - | - |
| Horizontal | 150 | 200 | 19 | - | - | - |
Hardness
| EN ISO 6506 Heat Treated | |
|---|---|
| Value | 95 |
| Unit | HBW 2.5/62.5 |
| EN ISO 6506 As Manufactured | |
|---|---|
| Value | 55 |
| Unit | HBW 2.5/62.5 |
Surface Roughness
| Surface Roughness | From | To |
|---|---|---|
| Sa (µm) | - | - |
| Ra (µm) | - | - |
Electrical Conductivity
| Orientation | Typical Electrical Conductivity [%IACS] | |
|---|---|---|
| As Manufactured | 60 µm | | Vertical | 28 |
| As Manufactured | 60 µm | | Horizontal | 28 |
| Orientation | Typical Electrical Conductivity [%IACS] | |
|---|---|---|
| Heat Treated | 60 µm | | Vertical | 46 |
| Heat Treated | 60 µm | | Horizontal | 46 |
Coefficient of Thermal Expansion
| Temperature | |
|---|---|
| 19*10-6/K | 25 – 100 ºC |
| 21*10-6/K | 25 – 200 ºC |
| 22*10-6/K | 25 – 300 ºC |
Process Data Sheet
EOS Aluminium Constellium CP1 for EOS M 400-4 | 60 µm
EOS M 400-4 - 60 µm - TRL 3
| System Setup | EOS M 400-4 |
|---|---|
| EOS Material set | AlCP1_060_M404 |
| Powder Product No. | 9030-0034 |
| Software Requirements |
EOSPRINT 2.13 or newer |
| Recoater Blade | HSS (High Speed Steel) |
| Build Platform Temperature | 150 °C |
| Nozzle | EOS Aerospike Nozzle |
| Inert gas | Argon |
| Sieve | 90 µm |
| Additional Information | |
|---|---|
| Layer Thickness | 60 µm |
| Volume Rate | up to 4 x 10.1 mm³/s |
Chemical and Physical Properties of Parts
Microstructure of the Produced Parts
| Defects | Thickness | Result | Number of Samples |
|---|---|---|---|
| Average Defect Percentage | 60 µm | 0.4 % | - |
| Density EN ISO 3369 | Thickness | Result | Number of Samples |
|---|---|---|---|
| Average Density | 60 µm | ≥ 2.73 g/cm³ | - |
Mechanical Properties
Mechanical Properties Heat Treated
| EN ISO 6892-1 Room Temperature | 60 µm | Yield Strength [MPa] | Tensile Strength [MPa] | Elongation at Break A [%] | Reduction of Area Z [%] | Modulus of elasticity [GPa] | Number of Samples |
|---|---|---|---|---|---|---|
| Vertical | 300 | 330 | 11 | - | - | - |
| Horizontal | 290 | 325 | 13 | - | - | - |
4 hours at 400 °C
No careful control needed for heating or cooling.
Mechanical Properties As Manufactured
| EN ISO 6892-1 Room Temperature | 60 µm | Yield Strength [MPa] | Tensile Strength [MPa] | Elongation at Break A [%] | Reduction of Area Z [%] | Modulus of elasticity [GPa] | Number of Samples |
|---|---|---|---|---|---|---|
| Vertical | 130 | 200 | 19 | - | - | - |
| Horizontal | 140 | 200 | 19 | - | - | - |
Hardness
| EN ISO 6506 Heat Treated | |
|---|---|
| Value | 99 |
| Unit | HBW 2.5/62.5 |
| EN ISO 6506 As Manufactured | |
|---|---|
| Value | 57 |
| Unit | HBW 2.5/62.5 |
Surface Roughness
| Surface Roughness | From | To |
|---|---|---|
| Sa (µm) | - | - |
| Ra (µm) | - | - |
Electrical Conductivity
| Orientation | Typical Electrical Conductivity [%IACS] | |
|---|---|---|
| Heat Treated | 60 µm | | Vertical | 46 |
| Heat Treated | 60 µm | | Horizontal | 46 |
| Orientation | Typical Electrical Conductivity [%IACS] | |
|---|---|---|
| As Manufactured | 60 µm | | Vertical | 28 |
| As Manufactured | 60 µm | | Horizontal | 28 |
Coefficient of Thermal Expansion
| ASTM E228 | Temperature |
|---|---|
| 19*10-6/K | 25 – 100 ºC |
| 21*10-6/K | 25 – 200 ºC |
| 22*10-6/K | 25 – 300 ºC |
