EOS StainlessSteel 316L-4404

Material Data Sheet

EOS StainlessSteel is a high-performance, marine-grade austenitic stainless steel that is molybdenum alloyed for enhanced corrosion resistance in chloride environments. 316L is a standard material for numerous applications in process, energy, paper, transportation, and other industries. EOS Stainless Steel 316L-4404 has a chemical composition corresponding to DIN EN 10088-3. All EOS StainlessSteel 316L parameter sets are compatible with EOS StainlessSteel 316L-4404 powder.

MAIN CHARACTERISTICS

High ductility and toughness
High strength
High corrosion resistance

TYPICAL APPLICATIONS

Chemical industry
Food processing
Water handling and marine applications

The EOS Quality Triangle

EOS uses an approach that is unique in the AM industry, taking each of the three central technical elements of the production process into account: the system, the material and the process. The data resulting from each combination is assigned a Technology Readiness Level (TRL) which makes the expected performance and production capability of the solution transparent.

EOS incorporates these TRLs into the following two categories:

Premium products (TRL 7-9): offer highly validated data, proven capability and reproducible part properties.
Core products (TRL 3 and 5): enable early customer access to newest technology still under development and are therefore less mature with less data.

All of the data stated in this material data sheet is produced according to EOS Quality Management System and international standards

POWDER PROPERTIES

The chemical composition of EOS stainlessSteel 316L-4404 is in compliance with DIN EN 10088-3.

Powder Chemical Composition (wt.-%)

Element	Min.	Max.
Fe	Balance
Cr	16.5	18.5
Ni	10.0	13.0
Mo	2.0	2.5
C	-	0.03
N	-	0.1
Si	-	1.0
Mn	-	2.0

Powder Particle Size

GENERIC PARTICLE SIZE DISTRIBUTION	20 - 65 μm

HEAT TREATMENT

Description

Optional according to DIN EN 10088-3

Steps

Stress relieve: Hold temperature 900 C, hold time minimum 2 h when throughly heated, water quenching or high speed gas quenching. Cooling rate to be high enough to prevent chromium carbide precipitation.

Solution annealing: Hold temperature 1100 C, hold time minimum 1,5 h when throughly heated, water quenching or high speed gas quenching. Cooling rate to be high enough to prevent chromium carbide precipitation.

Process Data Sheet

EOS StainlessSteel 316L-4404 for EOS M 290 | 40µm

EOS M 290 - 40 µm - TRL 3

Process Information Metal

EOS StainlessSteel 316L-4404 has chemical composition corresponding to DIN EN 10088-3. For more information reagrding the powder product, please refer to the EOS StainlessSteel 316L-4404 Material Data Sheet.

The following data was generated using the system and process described below. However, all EOS 316L parameter sets remain compatible with EOS StainlessSteel 316L-4404 powder.

System Setup	EOS M 290
EOS Material set	316L_040_FlexM291
Software Requirements	EOSPRINT 2.7 or newer EOSYSTEM 2.11 or newer
Recoater Blade	HSS (High Speed Steel)
Nozzle	EOS Grid Nozzle
Inert gas	Argon
Sieve	63 µm
