PA 2200 CarbonReduced Top Quality
Process Data Sheet
Process Information Polymer
PA 2200 CarbonReduced Top Quality
Product Description
The parameter set Top Quality is used for very small to medium-sized parts with extremely fine, fragile geometries and geometric elements and the strictest requirements in surface quality are best served by this parameter set. It applies a layer thickness of 60 µm, which is approximately the thickness of a grain of the plastic powder normally used today. The typical stair-step effect on upward and downward-pointing geometry elements can practically no longer be seen on TopQuality parts. The mechanical attributes of TopQuality parts are satisfyingly close to the levels of Performance parts.
| MECHANICAL PROPERTIES | DRY / CONDITIONED | UNIT | TEST STANDARD |
|---|---|---|---|
|
Tensile Modulus X Orientation Y Orientation Z Orientation |
1800 / - 1800 / - 1750 / - |
MPa MPa MPa |
ISO 527-1/-2 |
|
Tensile Strength X Orientation Y Orientation Z Orientation |
52 / - 52 / - 52 / - |
MPa MPa MPa |
ISO 527-1/-2 |
|
Nominal Strain at Break X Orientation Y Orientation Z Orientation |
20 / - 20 / - 7 / - |
% % % |
ISO 527-1/-2 |
|
Shore D Hardness X Orientation |
75 / - |
- |
ISO 7619-1 |
| OTHER PROPERTIES | VALUE | UNIT | TEST STANDARD |
|---|---|---|---|
| Powder Color | white | - | - |
| Components Color | white | - | - |
