POLYMER SOLUTIONS
PA 2220 HighReuse
Material Data Sheet
PA 2220 HighReuse
Product Description
EOS PA 2220 HighReuse is a highly efficient polyamide 12 material serving a broad variety of applications thanks to its balanced property profile. With a reusability rate of 70 % it contributes to lower cost per part, less material waste and a reduced powder carbon footprint.
- Contibuting to reduced material waste and lower cost per part
- Balanced property profile
- White multipurpose material
- Easy to color with state-of-the-art solutions
- Eyewear in the consumer goods industry
- Structural components, e.g., brackets
- Production equipment like grippers, jigs and fixtures
- Spare parts like covers, e.g., in the automotive industry
- Functional parts for prototyping incl. integrated hinges or threads
| MECHANICAL PROPERTIES | DRY / CONDITIONED | UNIT | TEST STANDARD | DRY / CONDITIONED | UNIT | TEST STANDARD |
|---|---|---|---|---|---|---|
|
Tensile Modulus X Orientation Y Orientation Z Orientation |
1800 / 1500 1800 / 1500 1800 / 1300 |
MPa MPa MPa |
ISO 527-1/-2 | - | - | - |
|
Tensile Strength X Orientation Y Orientation Z Orientation |
48 / 45 48 / 45 48 / 42 |
MPa MPa MPa |
ISO 527-1/-2 | - | - | - |
|
Strain/Elongation at Break X Orientation Y Orientation Z Orientation |
10 / 14 9 / 15 8 / 12 |
% % % |
ISO 527-1/-2 | - | - | - |
|
Charpy Impact Strength (+23°C) X Orientation Y Orientation Z Orientation |
24 / - 23 / - 19 / - |
kJ/m² kJ/m² kJ/m² |
ISO 179/1eU | - | - | - |
|
Charpy Impact Strength (-30°C) Z Orientation |
18 / - |
kJ/m² |
ISO 179/1eU | - | - | - |
|
Charpy Notched Impact Strength (+23°C) X Orientation Y Orientation Z Orientation |
2,6 / - 2,3 / - 2,5 / - |
kJ/m² kJ/m² kJ/m² |
ISO 179/1eA | - | - | - |
|
Charpy Notched Impact Strength (-30°C) Z Orientation |
2,1 / - |
kJ/m² |
ISO 179/1eA | - | - | - |
|
Shore D Hardness X Orientation |
79 / - |
- |
ISO 7619-1 | - | - | - |
| THERMAL PROPERTIES | DRY / CONDITIONED | UNIT | TEST STANDARD | DRY / CONDITIONED | UNIT | TEST STANDARD |
|---|---|---|---|---|---|---|
| Melting Temperature | 176,5 | °C | ISO 11357-1/-3 | - | - | - |
|
Temperature of Deflection under Load 1.80 MPa X Orientation Z Orientation |
64 57 |
°C °C |
ISO 75-1/-2 | - | - | - |
| FIRE PERFORMANCE ELECTRICAL & ELECTRONICS |
RESULT | CONDITION / UNIT | TEST STANDARD |
|---|---|---|---|
| UL 94 Flammability Rating | HB, Test passed | class | UL 94 |
| Thickness Tested | 0.5 | mm | - |
| OTHER PROPERTIES | VALUE | UNIT | TEST STANDARD | VALUE | UNIT | TEST STANDARD |
|---|---|---|---|---|---|---|
| Density | 0.99 | g/cm³ | DIN EN ISO 1183-2 | - | - | - |
| Powder Color | white | - | - | - | - | - |
| Components Color | white | - | - | - | - | - |
